BXG03 Industrial dryer

Use：The industrial dehydrator uses the rotation of the inner tank to throw the liquid out of the mesh of the inner tank under the action of centrifugal force, thereby separating the solid and liquid to achieve the purpose of dehydration.

Features:
1. Various specifications to meet user output needs.
2. Independent machine, easy to operate and no installation required.
3. Stainless steel inner tank, effectively prevents corrosion, reduces wear on materials during dehydration, and is durable.

Main technical parameters：

Model	BXG03-15	BXG03-20	BXG03-30	BXG03-50	BXG03 -100	BXG03-120	BXG03-150
Capacity	15kg	20kg	30kg	50kg	100kg	120kg	150kg
Rotating Speed	32-35 r/min	32-35 r/min	32-35 r/min	30-33 r/min	30-33 r/min	29-31 r/min	29-31 r/min
Drum Size	Φ800 *500 mm	Φ800 *670 mm	Φ900 *800 mm	Φ1168 *1070 mm	Φ1320 *1100 mm	Φ1450 *1250mm	Φ1600 *1500mm
Dimensions	880* 1040* 1600 mm	1000* 1150* 1800 mm	1080* 1350* 1900 mm	1220* 1660* 2080 mm	1480* 1760* 2290 mm	1760* 1950* 2360 mm	1760* 2000* 2400 mm
Motor Power	1.5kw	2.2kw	4kw	5.5kw	7.5kw	7.5kw	10kw
Fan Power	0.75kw	0.75kw	0.75kw	1.1kw	2.2kw	3kw	4.4kw
Total Weight	450kg	500kg	600kg	800kg	980kg	1100kg	1300kg
Power Supply	Match the user's power supply
Heating Conditions	Steam pressure 0.4-0.6MPa Match the user's power supply
