Use：Fiber strips of various raw materials are made into core-spun yarn/thick count/extra-thick count yarn.
Features:
1. Applicable to various types of fibers, including but not limited to polypropylene, absorbent cotton, glass fiber, acrylic fiber, aramid and other special fibers.
2. It is very suitable for the production of various core-spun yarns, filter yarns, composite yarns, mop yarns, sealing yarns, flame-retardant yarns, etc.
3. Suitable for feeding carded sliver, combed sliver, needle carded sliver, pre-drawing, final-drawing sliver, carding into strips and other specifications.
Main technical parameters：
| Model |
MC-6 |
|
Suitable spinning fiber length |
10-120mm |
|
Suitable spinning fiber density |
1.2-15dtex |
|
Suitable spinning fiber types |
Natural plant fibers, animal fibers, and their regenerated fibers, velvet. |
|
Number of spindles |
6 |
|
Spindle pitch |
660mm |
|
Feed weight |
≤35g/m |
|
Feed the number of roots |
2-5 unit |
|
Feed can specifications |
200-600*900/1100mm |
|
Draft multiple |
≤1.05 |
|
Output speed |
239m/min（max） |
|
Output yarn diameter |
8mm（max） |
|
Yarn weight |
9kg（max） |
|
Host dimensions |
4180*818*1699mm |
|
Dimensions of electrical control cabinet |
818*350*1699mm |
|
Machine net weight |
2.68t |
|
Production area |
6000*6180mm |
|
Maximum installed power |
19.88kw |
