Use：It is used for merging and drafting slivers to make different fibers more even in the mixing, making the fibers straighter and more parallel.
Features:
1.PLC programmable controller.
2. The process parameters can be operated from the display screen.
3. Servo motors are precisely controlled.
Main technical parameters：
| Model |
LWYZ560 |
|
Adaptation |
Fiber length 22-76mm pure cotton, linen, wool, chemical fiber and their blends |
|
Sliver speed |
178-600m/min |
|
Feed sliver quantity |
3-8 |
|
Drafting method |
Four up and three down pressure rods + guide top rollers |
|
Total draft ratio |
4.0129-13.5558 |
|
Barrel changing method |
Chain push rod type |
|
Power |
10.25kw servo motor |
|
Feeding can |
400/500/600/1000*900/1100mm |
|
Output can |
350/400/500*900/1100mm |
